RFQ

Black Box - media converter - 10Mb LAN, 100Mb LAN, GigE

  • NG # 03495-HW-BLACK-028

  • MF # LGC5600A

Manufactured By :
Black Box
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Easily convert 10/100/1000BASE-T to 1000BASE-X SFP and provide PoE++ (up to 60 W) on the copper port. Convert 10/100/1000BASE-T to 1000BASE-X SFP with Ease If you need to extend your copper network with fiber look no further. PoE++ Media Converter easily converts 10/100/1000BASE-T to 1000BASE-X or 100BASE-X SFP. Power-over-Ethernet Support With full Power-over-Ethernet (PoE) support this media converter can function as a PoE injector. It's classified as Power Sourcing Equipment (PSE) and can provide power to one or two powered devices (PDs) using standard UTP cables. The converter provides up to 60 watts of power per RJ-45 port allowing it to power cameras wireless access points and more. Configurable Features Changeable features include link modes and a PoE power reset function that enables a PD device to be reinitialized remotely eliminating the need for costly trips to PD sites. Link modes can be configured to propagate loss-of-link faults to managed devices immediately notifying administrators of network outages. Works with a Variety of Fiber PoE++ Media Converter supports fixed-fiber connectors and 100-Mbps or 1000-Mbps SFP transceiver receptacles. It also supports SFPs for multimode and single-mode dual fiber as well as single-mode single fiber in standard and CWDM wavelengths. Plenty of Mounting Options This compact standalone media converter can be tabletop mounted wall-mounted or DIN-rail mounted using an optional DIN-rail mounting kit. It can also be mounted on a 1U 19-inch rackmount shelf.

Specification

General
Device Type
Media converter
Form Factor
External
Networking
Connectivity Technology
Wired
Cabling Type
10Base-T, 100Base-TX, 1000Base-T, 1000Base-X
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Features
Wall mountable, DIN rail mountable
Compliant Standards
IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Expansion / Connectivity
Interfaces
1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female ¦ 1 x network - SFP
Miscellaneous
Compliant Standards
UL, FCC, RoHS, REACH
Power
Power Over Ethernet (PoE)
PoE++
Power Device
External power adapter
Voltage Required
AC 120/230 V
Dimensions & Weight
Width
4.5 in
Depth
6 in
Height
1 in
Weight
17.64 oz
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
Environmental Parameters
Humidity Range Operating
5 - 95% (non-condensing)
