NG # 00437-HW-ECOM-038
The Ex-MX2 is designed for measuring temperatures in challenging environments, particularly for objects that are hard to reach or materials in motion within explosive areas.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe sighted measuring area can be very clearly recognised using the 3-point measuring area marking, and the device can be adjusted and matched to the most diverse materials using the emissivity setting (in 0.01 increments). An exact measurement result is obtained in this way.
Specification
| TEMPERATURE RANGE: | -30 °C … +900 °C (-22 °F … +1,652 °F) |
| ACCURACY (25 °C): |
±0.75 % of the measured value or ±0.75 K , whichever is greater (±2 K for measurement objects below -5 °C) |
| SYSTEM FAILURE (AT 25 °C ±25 K): |
< 0.05 K/K or < 0.05 %/K, whichever is greater |
| REPEATABILITY: | ±0.5% of the measured value or ±0.5 K, whichever is greater |
| RESPONSE TIME (95%): | 250 ms |
| DISPLAY RESOLUTION: | 0.1 °C (with temperature) |
| EMISSIVITY: | 0.10 … 1.50 (per 0.01) |
| SPECTRAL RESPONSE: | 8 μm … 14 μm |
| DISPLAY | Current temperature, MIN/MAX trend bar (last 10 measuring points), laser warning symbol, emission level, battery status |
| LASER CLASS | Class 2 |
| HUMIDITY | 10-95% r.H. at 30 °C (86 °F) (non-condensing) |
| AMBIENT TEMPERATURE | ±0 °C … +50 °C (+32 °F … +122 °F) with laser max. +45 °C (+113 °F) |
| STORAGE TEMPERATURE | -20 °C … +50 °C (-4 °F … +122 °F) |
| POWER SUPPLY | 2x LR6 (AA) according to IEC (type approved) |
| DIMENSIONS | 200 mm x 170 mm x 50 mm (~ 7.9" x 6.7" x 2") |
| WEIGHT | approx. 600 g (~ 21.2 oz) |
Data Sheet
