Installing a high performance fiber optic cabling system starts with systems design and ends with systems acceptance. Certifying cabling to industry performance standards is a core element of the process. The faster it goes, the more profitable you’ll be. Unfortunately, there are a lot of things that slow the process down - setting the tester up incorrectly, testing to the wrong limits, waiting for lead technicians to analyze or troubleshoot failures, misinterpretation of results, and test reports that customers can't understand.
Specification
| Wavelengths | 850 nm, 1300 nm, 1310 nm, 1550 nm |
| Power Measurement Range | 0 dBm to -65 dBm (850 nm) 0 dBm to -70 dBm (all other wavelengths) |
| Power Measurement Uncertainty 1,2 | < ±5% ±32 pW |
| Testing Speeds (excludes referencing times) | Smart Remote mode: < 3 seconds (2 wavelengths, one direction, auto wavelength detection), Far End Source mode: ≤ 2 seconds (2 wavelengths, one direction auto wavelength detection), Loopback mode: ≤ 2 seconds (2 wavelengths, one direction auto wavelength detection) |
| Input/Output Connectors | Interchangeable connector adapter (LC standard, SC, ST and FC optional) |
| Launch Condition 1,2 | Encircled Flux compliant to TIA-526-14-B, ISO/IEC 14763-3 and IEC 61280-4-1 |
| Fiber Types Tested | Singlemode |
| Source Type and Wavelengths | Fabry-Perot laser diode 1310 nm ± 20 nm 1550 nm ± 30 nm |
| Maximum Length Measurement | 130 km |
| Length Measurement Accuracy | ± 1.5 m plus ± 1% of length |
| Output Power (Nominal) | ≤ -4 dBm |
| Output Power Stability 3 | ± 0.1 dB over 8 hours ± 0.08 dB over 15 minutes |
| Output Power | < -5 dBm, <0 dBm, SMF-28 singlemode fiber Continuous wave, SC/UPC connector |
| Operating Wavelength | 650 nm nominal |
| Output Modes | Continuous wave, Pulsed mode (2 Hz to 3 Hz blink frequency) |
