Lindy 2m Thunderbolt 4 Cable, 40Gbps, active

  • 02337-HW-LIndy-014

  • 02337-HW-LIndy-014

  • 02337-HW-LIndy-014

The Lindy 2m Thunderbolt 4 Cable provides the full Thunderbolt 4 specification with data transfer rates up to 40 Gbps.

Manufactured by:

Lindy

Need Help Ordering?
Call +88 01714243446

Stock
5 in stock

Custom Pricing

Get A Quote
Need Help Ordering?
Call +88 01714243446

Stock
5 in stock

Custom Pricing

Get A Quote

Overview

It is backwards compatible and delivers up to 20Gbps for USB 3.2 devices. It supports connecting a 8K or dual 4K UHD displays for stunning contrast and colour depth.

This cable is Thunderbolt certified and can provide 100W (5A) of power to Thunderbolt 4 and USB Type C devices using the most efficient power delivery profiles.

Specification

Connectors

  • Connector A: Thunderbolt 4 USB Type C Male with E-Mark
  • Connector B: Thunderbolt 4 USB Type C Male
  • Housing Material: PC
  • Shielding in head shell: -
  • Connector Plating: Nickel
  • Pin Construction: -
  • Pin Plating: Nickel
  • Dimensions (approx.) WxDxH: 12.35x27x6.5mm (0.49x1.06x0.26in)

Cable Construction

  • Length: 2m (6.56ft)
  • Standard: Thunderbolt 4
  • Power Delivery: PD 3.0 up to 100W (20V 5A)
  • Colour: Black
  • Type: Round
  • Jacket Diameter: 4.6mm (0.18in)
  • Jacket Material: TPE
  • Conductor Material: Copper
  • Conductor Gauge Power: 24AWG
  • Conductor Gauge Data: 30AWG
  • Shielding: Braid

Specifications

  • Supported Bandwidth: 40Gbps
  • Maximum Resolution: 4096x2160@120Hz, 7680x4320@60Hz
  • Nominal Attenuation: -
  • Minimum Bend Radius: 46mm (1.18in)
  • Operating Temperature: 10°C - 40°C (50°F - 104°F)
  • Storage Temperature: -10°C - 50°C (14°F - 122°F)

Miscellaneous

  • Packaging Type: Polybag
  • Warranty (Years): 2
  • Product Compliance: CE, UKCA, FCC, RoHS, REACH, California Proposition 65
