RFQ

ASCO™ SC8551A005MS.24/50-60

  • NG # 0654301-HW-ASCO-301

ASCO™ SC8551A005MS.24/50-60 is a pilot-operated 3/2-way solenoid valve designed for reliable fluid control in industrial applications. It features a manual screw-type operator, 1/4-inch (DN8) NPT connection, and a 6.0 mm orifice. Constructed with an aluminium body and urethane sealing, the valve provides dependable operation. Its monostable configuration and 2.5 W Class F coil support efficient and consistent switching performance in demanding pneumatic and automation systems.





Manufactured By :
ASCO
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The ASCO™ SC8551A005MS.24/50-60 is a 3/2-way pilot-operated solenoid valve with a 1/4-inch NPT connection and 6.0 mm orifice. Featuring aluminium construction, urethane sealing, manual screw operation, and a 2.5 W Class F coil, it provides reliable fluid control for industrial automation applications.

Specification

Body MaterialLight Alloy
Flow (Cv) / Flow (Kv)0.87 / 0.75
Function3/2 Normally Closed
Pipe/Port Type & SizeNPTF 1/4
Product TypeSolenoid Valve
Valve ActuationSolenoid - Pilot Operated
MediaAir, Inert Gas
Min to Max Operating Pressure (Air)2 - 10 bar
Product Weight0.35 kg
Coil ClassF
Min to Max Ambient Temperature-25 - 60 °C
Min to Max Fluid Temperature-25 - 60 °C
Orifice Size6 mm
Voltage25 Volts AC with 50, 60 Hz
Watt Rating2.5 W
ConnectorIncluded (EN175301-803, industry standard form B)
