Testo 176-P1 5-Channel Pressure/Temperature/Humidity Data Logger with external NTC

  • NG # 01850-HW-TESTO-058

  • MF # 0572 1767

Five-channel data logger with internal absolute pressure sensor and external NTC/capacitive humidity sensor is ideal for the monitoring of pressures, temperatures, and humidity. Capable of storing 2,000,000 measurement values.

Manufactured By :
Testo
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Testo 176 P1 is the right data logger when ambient conditions need to be accurately documeted. It has an internal absolute pressure sensor and external sensor connections (NTC/capacitive humidity sensor). Five-channel data logger with internal absolute pressure sensor and external NTC/capacitive humidity sensor is ideal for the monitoring of pressures, temperatures, and humidity. Capable of storing 2,000,000 measurement values.

Specification

Specification

Memory 2,000,000 values
Storage temperature -40 to +85 °C
Operating temperature -20 to +70 °C
Dimensions 103 x 63 x 33 mm
NTC
Measuring range -20 to +70 °C
Accuracy ±0.2 °C (-20 to +70 °C)
±0.4 °C (remaining range)
Resolution 0.1 °C
Humidity
Measuring range 0 to 100 %RH
Resolution 0.1 %RH
Pressure Probe
Measuring range 600 to 1100 mbar
Accuracy ±3 mbar (0 to +50 °C)
Resolution 1 mbar
