TS-3XX Temperature Sensor

  • NG # 0532204-HW-EMS-204

TS-3XX is a precise temperature sensor designed for reliable environmental measurement. It supports NTC-10K, NTC-30K, PT-100, and PT-1000 sensing elements, offering accurate performance, long operating life, easy assembly, and an IP67-rated plastic case.





Manufactured By :
EMS Control
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The TS-3XX Temperature Sensor provides dependable temperature monitoring across industrial and environmental applications. It operates across a -40 to +80°C measuring range, with ±0.1°C sensitivity. Available in NTC and PT sensor configurations, it offers accuracy up to ±0.1°C depending on model. The sensor includes an IP67 plastic case, customizable 0–10 m cable length, and selectable 50 mm or 100 mm metal probe lengths, supporting flexible installation.

Specification

Product Name: TS-3XX Temperature Sensor
Sensor Type: NTC-10K / NTC-30K / PT-100 / PT-1000
Measuring Range: -40 to +80°C
Sensitivity: ±0.1°C
NTC-10K Accuracy: ±0.5°C
NTC-30K Accuracy: ±0.5°C
PT-100 Accuracy: ±0.5°C
PT-1000 Accuracy: ±0.1°C
NTC-10K Beta Value: B25/85 – 3435K
NTC-30K Beta Value: B0/50 – 3892K
Sensor Cable Length: 0–10 m, customizable
Metal Probe Length: 50 mm / 100 mm
Protection Rating: IP67
Dimensions: 135 × 58 × 35 mm
Product Codes: TS-311 / TS-312 / TS-321 / TS-331
