Allen Bradley 1762 Series PLC I/O Module for Use with MicroLogix 1100 Series, MicroLogix 1200 Series, MicroLogix 1400

  • NG # 02741-HW-ALBR-080

  • MF # 1762-IF4

Manufactured By :
Allen Bradley
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Analogue I/O Modules


Voltage or Current inputs
Dimensions: H 90 x W 40 x D 87mm


Note

Installations subject to high vibration should be panel mounted (as opposed to DIN rail mounted). A 50mm space should be left on all sides around units to provide adequate ventilation.

Allen Bradley Analogue Input Module For Use With MicroLogix 1100, 1200, 1400 Series, 4 Channels - 1762-IF4


This analogue input module from Rockwell Automation's Allen Bradley range is designed to monitor machine operating conditions. It also transfers signals to a programmable logic controller (PLC) for easy diagnosis. The unit features four channels that enable a wide range of voltage and current monitoring functions from a single unit. Thanks to its compact dimensions of 90mm (height), 40mm (width) and 87mm (depth), this module fits easily in busy panels to maximise space. Use it to manage automated assembly lines in industrial environments.


Features & Benefits


• Wide operating temperature range between 0°C and +55°C for use in diverse environments
• Differential or single-ended inputs for added versatility
• Repeatability rate of ±0.1% ensures accurate results in multiple readings
• LED (light-emitting diode) signal to quickly notify you if power is applied
• High output current of ±21mA for use with heavy-duty equipment


Standards and Certifications


• ANSI/ESD (American National Standards Institute)
• BS (British Standard)


What controllers can I use this module with?


This unit is compatible with controllers from the MicroLogix 1100, MicroLogix 1200 and MicroLogix 1400 ranges, making it a versatile choice.

Specification

Accessory TypePLC I/O Module
Series1762
Input TypeAnalogue
Number of Inputs4
Output TypeTransistor
For Use WithMicroLogix 1100 Series, MicroLogix 1200 Series, MicroLogix 1400 Series
Output Current±21 mA
Maximum Operating Temperature+55°C
Dimensions87 x 40 x 90 mm
