Contactless Incremental Encoder

  • NG # 06770323-HW-TURCK-023

Contactless Encoder – RI360P0-QR24M0-0010X2-H1181 is a precision incremental encoder designed for reliable, wear-free rotational measurement. With 10 PPR resolution, contactless inductive technology, hollow-shaft construction, Push-Pull/HTL output, and IP68/IP69K protection, it provides dependable feedback for demanding industrial automation applications. 





Manufactured By :
TURCK
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Contactless Encoder – RI360P0-QR24M0-0010X2-H1181 combines contactless inductive sensing with a robust hollow-shaft design to deliver dependable rotational feedback without mechanical wear. Its 10 PPR incremental resolution supports consistent motion monitoring, while the Push-Pull/HTL output enables straightforward integration with industrial control systems. The metal/plastic housing and IP68/IP69K protection provide excellent resistance to demanding environmental conditions. With an M12 × 1 connection and an operating temperature range of -25 to +85°C, it is well suited for reliable machine automation and motion-control applications.

Specification

Ambient Temperature: -25 to 85°C
Connector Type: M12 × 1
Dimensions (L × W × H): 81 mm × 78 mm × 24 mm
Electrical Connection: Connector
Encoder Line: Premium-Line
Flange Type: Flange Without Mounting Element
Housing Material: Metal/Plastic
Housing Quality: ZnAlCu1/PBT-GF30-V0
Measuring Principle: Inductive
Operating Voltage: DC
Output Function: Push-Pull/HTL
Output Type: Incremental
Protection Class: IP68, IP69K
Resolution – Incremental: 10 PPR
Shaft Diameter: 6 mm, 6.35 mm, 9.525 mm, 10 mm, 12 mm, 12.7 mm, 14 mm, 15.875 mm, 19.05 mm, 20 mm
Shaft Type: Hollow Shaft
Technology: Contactless
