Incremental Encoder – REI-43H42S-2B600-H1181

  • NG # 06770322-HW-TURCK-022

Incremental Encoder – REI-43H42S-2B600-H1181 is a heavy-duty optical encoder designed for reliable rotational measurement in industrial automation. Featuring a large 42 mm hollow shaft, 600 PPR resolution, Push-Pull/HTL output, and IP65 protection, it provides stable and precise feedback for demanding machinery applications.





Manufactured By :
TURCK
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Incremental Encoder – REI-43H42S-2B600-H1181 combines robust mechanical construction with dependable optical measurement technology for demanding industrial applications. Its large hollow-shaft design simplifies integration with rotating machinery, while the 600 PPR incremental resolution enables consistent motion and speed feedback. A die-cast zinc housing and IP65 protection provide durability in industrial environments, while the Push-Pull/HTL output supports flexible control-system integration. With a 100 mm flange, M12 × 1 connection, and -40 to +80°C operating range, it is well suited for heavy-duty automation systems.

Specification

Ambient Temperature: -40 to 80°C
Connector Type: M12 × 1
Design: Hollow Shaft
Electrical Connection: Connector
Encoder Line: Industrial-Line
Flange Diameter: 100 mm
Flange Type: Flange Without Mounting Element
Housing Material: Die-Cast Zinc
Measuring Principle: Optical
Output Function: Push-Pull/HTL
Output Type: Incremental
Protection Class: IP65
Protection Class – Shaft: IP65
Resolution – Incremental: 600 PPR
Shaft Diameter: 42 mm
Shaft Type: Hollow Shaft
Special Features: Heavy Duty, Large Hollow Shaft
Technology: Optical
