Pressure sensor for high-pressure applications FKR - FCX-AIV V6 Series

  • NG # 03586-HW-FUJI-003

Manufactured By :
Fuji Electric
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

GAUGE PRESSURE TRANSMITTER - HIGH PRESSURE - FKR: RELIABILITY AND PERFORMANCE FOR DEMANDING INDUSTRIAL APPLICATIONS The high pressure gauge pressure transmitter FRK from Fuji Electric is designed to meet the demands of the most challenging industrial environments. Thanks to its mechanical robustness and measurement precision, it provides effective monitoring of high pressures across various sectors. Ideal for installations requiring strong overload resistance and long-term stability. FEATURES OF THE GAUGE PRESSURE TRANSMITTER - HIGH PRESSURE - FKR - Measurement range: up to 1500 bar - Silicon-based piezoresistive technology - Stainless steel housing for excellent corrosion resistance - Analog output 4-20 mA with HART digital signal superimposed on the analog signal - Compliant with SIL2 / SIL3 safety integrity levels APPLICATIONS Used for pressure monitoring in hydraulic circuits, machine tools, petrochemical, and processing industries. Also suitable for power plants, automotive component manufacturing, pressure testing equipment, and offshore engineering. ADVANTAGES High accuracy and low long-term drift Rugged construction for severe environments Wide compatibility with standard industrial systems Fast response time Easy to install and integrate

Specification

TypeIntelligent 4-20 mA Pressure transmitter with HARTTM 7 protocol
HousingL- or T-shaped housing
Measuring ranges (kPa) [e.max.]70 000
150 000
Weight per kg (without indicator)1.5
Accuracy±0.065%
Materials in contact with the processInconel® 625
Stainless steel 318 LN
Stainless steel 316L
Case materialsLow-copper die-cast aluminum alloy, coated with polyester (standard) or 316L stainless steel (optional).
Membrane materialsInconel® 625
Inconel® 625 and Gold plating
Stability±0.1% of upper range limit for 5 years
Elevation / Deletion-1 barg at 100% of full scale
Scale setting rangeFrom 1 to 1/16 of maximum scale
Measurement cycle40 ms
Communication protocolHARTTM 7 communication protocol
Process temperatureFrom -40 to 100°C
Ambient temperatureFrom -40 to +85°C
-20 to +80°C (with optional LCD unit)
-40 to +60°C (with optional lightning arrester)
Power supply10.5 to 45 V DC
Output signal / Load resistance4-20 mA / 250 Ω typical
DampingConfigurable from 0.04 to 32 seconds
Zero and span adjustmentVia external sensor screw, local three-button display or HARTTM protocol
Electrical connectionsM20×1.5" / 1/2 -14 NPT / Pg13.5
OptionsDigital indicator, degreasing treatment, oxygen service, chlorine service, additional stainless steel identification plate
