SUP-RD902T 26GHz Radar level meter

  • NG # 04090-HW-SUPMEA-045

  • MF # SUP-RD902T

The SUP-RD902T is a non-contact radar level meter designed for liquid level measurement in industrial tanks. It uses a 26 GHz high-frequency radar sensor and PTFE-coated antenna for accurate and reliable measurement in corrosive or aggressive environments.

Manufactured By :
Supmea
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The SUP-RD902T radar level meter is a continuous non-contact measurement instrument ideal for liquid level monitoring in various industrial applications. It features simple setup, robust performance with high measurement accuracy, and compatibility with standard industrial output interfaces. The device supports both two-wire and four-wire power supply configurations and can communicate through 4-20 mA, RS485, or Modbus outputs. Its PTFE sensor material and high-frequency radar technology make it suitable for use in corrosive liquids and environments requiring high precision and low maintenance.

Specification

Model

  • SUP-RD902T Radar Level Meter

Measurement Performance

  • Measurement Range: 0 to 20 meters
  • Accuracy:  ±3 mm
  • Frequency Range: 26 GHz

Application

  • Designed for non-contact liquid level measurement, including corrosive and aggressive fluids

Physical and Environmental

  • Process Connection: Thread or flange
  • Medium Temperature: -40 °C to 130 °C (standard type); -40 °C to 230 °C (high temperature type)
  • Process Pressure: -0.1 MPa to 2.0 MPa
  • Protection Grade: IP67

Signal and Interface

  • Signal Output: 4-20 mA
  • Digital Communication: RS485 / Modbus

Power Supply

  • Two-wire: DC 24 V
  • Four-wire: DC 6-24 V

Installation Notes

  • Recommended minimum distance of 200 mm from the tank wall for proper measurement performance
