SUP-RD905 Solid material radar level meter

  • NG # 04095-HW-SUPMEA-050

  • MF # SUP-RD905

The Supmea SUP‑RD905 Radar Level Meter is a high‑frequency radar sensor designed for continuous level measurement of solid and powdered materials. It uses microwave radar technology to monitor the distance between the sensor and material surface, providing reliable and accurate measurements for industrial applications. The device supports multiple output signals and offers robust performance under varying temperature and pressure conditions.

Manufactured By :
Supmea
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The SUP‑RD905 Radar Level Meter is engineered for accurate and continuous non‑contact level measurement of solids and powders in industrial environments. It operates at a high radar frequency of 26 GHz to ensure stable readings even in dusty or complex conditions. The sensor’s robust construction and IP67 protection make it suitable for varied applications where temperature and pressure fluctuate. With flexible signal outputs including analog 4–20 mA and digital RS485/Modbus communication, the unit easily integrates into control systems. Installation options include threaded and flanged connections to accommodate different mounting requirements.

Specification

· Product Type: Radar level meter

· Model: SUP‑RD905

· Measuring Range:

  • Liquids: 0–30 meters
  • Solid particles: 0–20 meters
  • Solid power: 0–15 meters

· Application: Solid particles, powder measurement

· Process Connection: Thread, flange

· Medium Temperature Range:

  • Standard: -40 °C to 130 °C
  • High temperature option: -40 °C to 230 °C

· Process Pressure Range:

  • Flat flange: -0.1 to 4.0 MPa
  • Universal flange: -0.1 to 0.3 MPa

· Accuracy: ±10 mm

· Ingress Protection: IP67

· Frequency Range: 26 GHz

· Signal Output:

  • 4–20 mA (two‑wire or four‑wire)
  • RS485 / Modbus

· Power Supply Options:

  • Two‑wire: DC 24 V
  • Four‑wire: DC 24 V or AC 220 V
