ProScan® 8000 Radar Liquid Level Sensor Transmitter

  • NG # 003122-HW-IPC-022

ProScan® 8000 Radar Liquid Level Sensor Transmitter measures liquid levels in tanks or sumps for corrosive and non-corrosive liquids using a PTFE Teflon antenna. Accurate and reliable without re-calibration, it handles foam and vapor, offers a 10 m range, simple programming, 26 GHz radar, EX ATEX rating, and 4–20 mA loop-powered output.






Manufactured By :
Icon Process Controls
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

ProScan® 8000 is a high-precision radar liquid level sensor transmitter designed for industrial tanks and sumps containing corrosive or non-corrosive liquids. Equipped with a PTFE Teflon antenna, it calculates liquid levels via low-energy radar pulse time-of-flight, delivering reliable, maintenance-free operation. The sensor supports foam and vapor environments, provides a 10 m measuring range, simple programming, 26 GHz radar, EX ATEX compliance, and 4–20 mA loop-powered output for versatile industrial applications.



Specification

Specification

Operating Range: 8 in – 33 ft (20 cm – 10 m)

Frequency: 26 GHz

Resolution: ±1 mm (0.04 in)

Repeatability: ±3 mm (0.11 in)

Response Time: 1.1 s

Sampling Rate: 55 / sec

Beam Angle: Narrow, focused signal

Housing Material: ABS or Polycarbonate

Antenna Material: PTFE Teflon®

O‑Ring Options: FKM, EPDM, FFKM

Supply Voltage: 9–36 VDC

Output Signals: 4‑20 mA, RS485

Communication Protocols: Modbus, HART

Operating Temperature: −40 °C to +130 °C (PTFE), 0 °C to +60 °C (ABS)

Enclosure Rating: NEMA 4X / IP67

Installation / Process Connection: NPT or flange

No Moving Parts: Virtually zero maintenance

Certifications: CE, FCC, RoHS
