Testo 868S Thermal Imaging Camera, 160 x 120, 80 mK

  • NG # 01551-HW-TESTO-023

  • MF # 01551-HW-TESTO-023

  • SKU # 01551-HW-TESTO-023

Smart with networked thermography, this thermal imager features SuperResolution technology that provides 320 x 240 pixels and thermal sensitivity of 80 mK. With the best thermal image quality, this imager has a 5 MP visual image output, ɛ-Assist, and automatically detects hot and cold spots.

Manufactured By :
Testo
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Suitable for various applications, this user-friendly imager is quick and accurate for detecting leaks, identifying overheated connections, pinpointing thermal bridges, and detecting structural defects. Additionally, this imager features ε-Assist, IFOV warner, and the ScaleAssist function.

Specification

Specification

Infrared Resolution160 x 120 pixels
Thermal Sensitivity (NETD)<0.14°F (0.08°C) (80 mK)
Field of View/Minimum Focusing Distance31 x 23°/<1.6' (0.5 m)
Geometric Resolution (IFOV)3.4 mrad
SuperResolution (Pixel/IFOV)320 x 240 pixels, 2.1 mrad
Image Refresh Rate9 Hz
FocusFixed
Spectral Range7.5 to 14 μm
Image Presentation
Image Display3.5" (8.9 cm) TFT, QVGA
Display OptionsIR image/real image
Color PalettesIron, rainbow HC, cold-hot, grey
General Specifications
MeasurementRanges
1: -22 to 212°F (-30 to 100°C)
2: 0 to 1202°F (0 to 650°C) manual/automatic switchover

Accuracy: ±3.6°F (±2°C), ±2% of measurement value (higher value applies)
Emissivity/reflected temperature compensation: 0.01 to 1/manual
ε-Assist: Automatic recognition of emissivity and determination of reflected temperature (RTC)
Measurement FunctionsAnalysis: Centre point measurement, hot/cold spot detection, delta T
ScaleAssist: Yes
IFOV warner: Yes
Lens31 x 23°
Video StreamingVia USB
via Wi-Fi with Thermography App
Imager StorageFile format: .bmt and .jpg; export options in .bmp, .jpg, .png, .csv, .xls
Memory: Internal memory (2.8 GB)
Wi-Fi ConnectivityCommunication with the thermography app wireless module Wi-Fi (EU, EFTA, USA, AUS, CDN, TR)
Image Size/Minimum Focusing Distance5 MP/minimum 1.6' (0.5 m)
Power SuppliesBattery type: Lithium-ion rechargeable battery exchangeable on site
Operating time: 4 hours
Charging option: In instrument
Temperature RangesOperating: 5 to 122°F (-15 to 50°C)
Storage: -22 to 140°F (-30 to 60°C)
Air Humidity20 to 80% RH, not condensing
Housing Protection Class (IEC 60529)IP54
Vibration (IEC 60068-2-6)2G
System RequirementsWindows 8.1 and 10
EU DirectiveEMC: 2014/30/EU
RED: 2014/53/EU
HousingPC - ABS
Dimensions8.6 x 3.8 x 3.7" (219 x 96 x 95 mm)
Weight1.12 lbs (510 g)
