NG # 0394417-HW-VEGA-417
EL 1 is a conductive rod electrode designed for reliable level detection in conductive liquids. With a robust, compact design and PTFE insulation, it provides dependable overfill and dry-run protection, particularly where installation space is limited and flexible probe length is required.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe EL 1 offers a simple and dependable approach to conductive liquid level monitoring. Its compact construction makes installation convenient even in restricted spaces, while the robust design helps minimize maintenance requirements and support long-term operational reliability. The probe can be shortened to suit different vessel requirements, providing greater installation flexibility. When combined with VEGATOR 131 or 132 controllers, it delivers practical overfill and dry-run protection for a wide range of industrial liquid-handling applications.
Process Temperature: -50 to 130°C
Process Pressure: -1 to 63 bar
Version: 1 Rod Electrode
Wetted Parts Materials: PTFE, 316L, Alloy C4 (2.4610)
Threaded Connection: G½
Seal Material: No Media Contact
Housing Material: Stainless Steel (Precision Casting)
Protection Rating: IP66/IP67
Output: For Connection to a Controller
Ambient Temperature: -40 to 80°C
