VEGAPULS C 22 Wired Radar Level Sensor

  • NG # 0394405-HW-VEGA-405

VEGAPULS C 22 is a wired 80 GHz radar sensor for continuous, non-contact level measurement of liquids and bulk solids. It delivers ±2 mm accuracy, up to 20 m measuring range, and reliable operation in demanding environments with high IP66/IP68 protection.





Manufactured By :
VEGA
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The VEGAPULS C 22 is designed for standard level measurement applications such as water treatment, pumping stations, rain overflow basins, open-channel flow measurement, and small bulk-solid containers. Its maintenance-free 80 GHz radar technology provides accurate measurement independent of the medium and environmental conditions.

Specification

Measuring Range – Distance: 20 m
Process Temperature: -40 to 80°C
Process Pressure: -1 to 3 bar
Accuracy: ±2 mm
Frequency: 80 GHz
Beam Angle: 8°
Wetted Parts Material: PVDF
Threaded Connection: G1½, 1½ NPT, R1½
Seal Material: FKM
Housing Material: Not specified
Protection Rating: IP66/IP68 (3 bar), Type 6P
Output: 4–20 mA/HART, Modbus, SDI-12
Ambient Temperature: -40 to 80°C
