NG # 0394414-HW-VEGA-414
VEGASWING 61 is a universal vibrating level switch for reliable point-level detection in liquids. Its precise, product-independent switching technology provides dependable performance regardless of mounting position, making it ideal for overfill protection, dry-run protection, pump protection, and level monitoring. It detects the limit level reliably and with millimetre accuracy directly at the mounting position. Numerous process fittings, approvals as well as housing and electronics versions.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteVEGASWING 61 is a universal level switch for use in all liquids. Independent of the mounting position, it detects reliably with millimetre accuracy the limit level. The instrument can be used as empty or full detector, as approved overfill protection, dry run protection or pump protection in vessels and pipelines. The VEGASWING 61 offers maximum reliability in a wide application range.
Process Temperature: -50 to 250°C
Process Pressure: -1 to 64 bar
Versions: Standard, Hygienic Applications, Gas-Tight Leadthrough, Temperature Adapter
Wetted Parts Materials: PFA, 316L, Alloy C22 (2.4602), Alloy 400 (2.4360), ECTFE, Enamel
Threaded Connection: ≥ G¾, ≥ ¾ NPT
Flange Connection: ≥ DN25, ≥ 1"
Hygienic Fittings: Clamp ≥ 1" (DIN 32676, ISO 2852); Slotted Nut ≥ 1½" / ≥ DN40 (DIN 11851); Varivent ≥ DN25; Hygienic Fitting F40 with Compression Nut; SMS 1145 DN51; SMS DN38; Hygienic Fittings ≥ DN25 (DIN 11864-1-A); Hygienic Flange Connection DIN 11864-2-A, DN60 (ISO) Ø60.3; SMS Socket Piece DN38 PN6
Seal Material: No Media Contact
Housing Materials: Plastic, Aluminium, Stainless Steel (Precision Casting), Stainless Steel (Electropolished)
Protection Rating: IP66/IP67, IP66/IP68 (1 bar), IP65
Output: Relay (DPDT), Contactless Electronic Switch, Transistor (NPN/PNP), Two-Wire, NAMUR
Ambient Temperature: -40 to 70°C
