RFQ

Pepperl+Fuchs Inductive sensor NBB15-30GM50-A2-V1

  • NG # 04148-HW-PEP-031

  • MF # NBB15-30GM50-A2-V1

The PXV000005M-AAMG30x500-000995 is a durable DataMatrix metal code bar designed for precise positioning applications with safePXV and safePGV read heads. It features high mechanical stability, excellent chemical resistance, and strong temperature tolerance, making it suitable for demanding industrial environments such as automated guided vehicle (AGV) navigation and positioning systems.

Manufactured By :
Pepperl+Fuchs
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The PXV000005M-AAMG30x500-000995 metal code bar is an industrial positioning component used with optical reading systems to enable accurate navigation and location detection in automation applications. Constructed from aluminum with a robust design, it provides reliable operation in harsh industrial conditions, including exposure to chemicals, oils, and varying temperatures.

The code bar incorporates two-colored Data Matrix codes that allow precise reading and positioning when used with compatible sensor systems. With adhesive mounting and modular segments, the code bar is easy to install, replace, and maintain. Its high durability and resistance to environmental factors make it ideal for logistics systems, conveyor automation, and automated vehicle guidance systems.

Specification

  • Product Type: Metal DataMatrix Code Bar
  • Manufacturer: Pepperl+Fuchs
  • Model: PXV000005M-AAMG30x500-000995
  • Application: Positioning for safePXV and safePGV read heads
  • Code Type: Two-colored Data Matrix codes
  • Total Length: 5 m
  • Start Position: 995 m
  • Nominal Segment Length: 500 mm
  • Code Bar Width: 30 mm

Mechanical Specifications

  • Material: Aluminum
  • Material Thickness: 1 mm
  • Mounting Type: Adhesive mounting
  • Mass: 83 g/m
  • Manufacturing Tolerance: ±1 mm/m

Environmental Conditions

  • Operating Temperature: -40 °C to 80 °C
  • Installation Temperature: 10 °C to 40 °C
  • Environmental Resistance: UV radiation and humidity resistant

Chemical Resistance

  • Resistant to oils
  • Resistant to grease
  • Resistant to fuels
  • Resistant to aliphatic solvents
  • Resistant to weak acids

Storage

  • Maximum storage period: 2 years under normal storage conditions
