RFQ

Pressure Control Valves HPB 08

  • NG # 04071-HW-coax-016

The HPB 08 is a series of externally controlled pressure control valves designed to regulate system pressure within industrial fluid applications. Featuring compact port connections and robust electrical interfaces, the valve is suitable for controlling pressure in systems with gaseous or liquid media while maintaining high duty cycles and environmental protection.

Manufactured By :
COAX
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The HPB 08 pressure control valve by müller co-ax is engineered for precise pressure regulation in fluid power systems. It operates within a wide pressure range and connects with standard industrial fittings. Designed for industrial environments, it supports continuous duty and offers reliable performance for diverse applications involving liquid or gaseous media. The valve’s technical design may vary depending on specific media and application requirements.

Specification

Technical Specifications

  • Port thread size: G 3/8 (standard industrial connection)
  • Pressure regulation range: 10–200 bar
  • Settling time: Less than 200 ms
  • Media type: Suitable for gaseous and liquid media
  • Media temperature range: 0 °C to +60 °C
  • Ambient temperature range: 0 °C to +50 °C
  • Insulation rating: H (180 °C)
  • Protection class: IP65 for environmental sealing
  • Energized duty rating: ED 100 % continuous duty allowed

Electrical & Connection

  • Electrical connection type: Standard plug according to DIN EN 175301-803, form A
  • Connector positions: 4 positions at 90°
  • Wire diameter compatibility: 6–8 mm
  • Alternative connection: M12x1 connector per DESINA/VDMA standard

Application Notes

  • Technical design may be adapted based on specific media properties and system requirements.
